Attention
Never mount the solar panel behind glass. Ensure that the
solar panel is shadow-free and clear of snow at all times and
receives as much direct sunlight as possible. The optimal
alignment for the solar panel is facing south with an inclina-
tion of approx. 30° relative to the horizontal. Do not exert
pressure on the photovoltaic cells under any circumstances,
as they can break very quickly. Position the connecting cable
in such a way that it cannot be damaged by the shading solu-
tion.
Drilling plan
Drill holes for a left-mounted solar panel
18
7
Drill holes for a right-mounted solar panel
26 - en
Mounting the solar panel
405
405
18
7
