Programming the transmitter

1. Connect the radio receiver to the power supply.
2. Now switch on the power.
3. The radio receiver remains ready for programming for 3 minutes.
Programming the master transmitter
The master transmitter refers to the very first transmitter
programmed in a receiver. In contrast to subsequently pro-
grammed transmitters, the master transmitter enables,
among other things, the setting of limit positions (for drives
with integrated radio receiver) and the programming or de-
leting of further transmitters. Any transmitter that has separ-
ate UP, STOP, DOWN buttons and a programming button can
be a master transmitter.
If a transmitter is already programmed in the receiver, press
the programming button of the transmitter for 10 seconds.
Press the programming button of the transmitter for 3 seconds whilst in pro-
gramming mode.
► The receiver confirms programming, i.e. the shading solution moves a
few centimetres before reversing the same distance.
The programming process is now complete.
