Cleaning The Filters; Battery Disposal - Bosch move Gebrauchsanweisung

(Innenteil) BBHmove 05/12
en
Crevice nozzle
12
Figure
For vacuuming crevices and corners, etc.
Insert the crevice nozzle into the air intake opening
of the handheld vacuum cleaner, as illustrated.
13
Figure
To charge the handheld vacuum cleaner, insert it into
the handstick vacuum cleaner and lock into place.
Make sure it is correctly seated.

Cleaning the filters

As far as possible, the dust container should be
emptied every time after vacuuming.
14
Figure
Remove the handheld vacuum cleaner from the
handstick vacuum cleaner (see Figure 11)
Using the release button, unlock the dust container
and withdraw it from the suction unit.
15
Figure
Using the handle, remove the dirt filter and cloth
filter from the dust container and clean them by
tapping out or brushing out the dirt with the brush
provided.
16
Figure
Empty the dust container.
If heavily soiled, the filters and dust container can be
washed out.
Then wipe out the dust container with a dry cloth.
Allow the filters to dry completely before refitting.
17
Figure
a)Insert the dirt filter and cloth filter into the dust
container.
b) Fit the dust container onto the suction unit and lock
into place.
Filters can be obtained from our after-sales service as
required
Cleaning the floor tool
18
Figure
The floor tool should be cleaned at regular intervals.
To clean it, release the floor tool from the handstick
vacuum cleaner. (see Figure 5)
Cut through threads and hairs wound round the
rollers using scissors.
Vacuum threads and hairs with the crevice nozzle.
24.05.2012 10:01 Uhr
Care
Before cleaning, the handheld vacuum cleaner or hand-
held appliance must be switched off and disconnected
from the charger. They can be cleaned using an ordinary
cleaning agent for plastics.
!

Battery disposal

Before disposing of the appliance, please remove the
battery cartridge and dispose of it separately.
Figure
Seite 9
Do not use a scourer, glass-cleaning agent or all-
purpose cleaning product. Never immerse the vacuum
cleaner in water
19
Slide open the battery compartment in the direction
of the arrow.
Cut through the retaining tape and remove the
battery cartridge from the appliance.
Cut through the power cables and to ensure safety,
bind and insulate each of the cable ends with tape.
9
