OPERATING INSTRUCTIONS
• Remove the lens caps from the objective lens (4) and from the long-range IR-illuminator (5).
• Press the button marked «ON» (6)toturn on the device. Astable green light indicates that the device is readyfor use. A
flashing green light indicates that the battery power level is low. A flashing red light indicates that the battery is empty.
• Locate an object within 20 to 30 meters.
• Adjust the sensitivity of the device (visually itis determined as image brightness) by turning the adjustment wheel (11).
• Rotate the eyepiece (7) and the objective (4) until you see a sharp image. When you turn the device on, the auxiliary
short-range IR-illuminator is turned on automatically.
Choose the operation modes of the IR-illuminator:
decrease respectively the power of the IR-illuminator.
operating time. If the device is focused on an object closer than 15 metres, the emission spot of the main IR-illuminator
(bright light circle) will be shifted to the right side ofthe display.
• When changing the viewing distance, try to see a sharp and high-quality
sensitivity adjustment wheel (11) and by changing
eyepiece (7) the device is already individually adjusted.
• Plug the output video cable into the Ranger
external LCD monitor. When the Ranger 5x42 is coupled with video equipment, the image observed can be recorded.
• To connect the Ranger 5x42 to a vehicle's 12V auxiliary power port, plug the car adapter into the Ranger's
input jack (13) and connect the other end of the cable to the vehicle's auxiliary power port.
• Toconnectthe Ranger5x42toa household outlet, usea variable power switching adapter.
Be careful, observe the polarity shown on the inner side of the battery cover.
NOTE. When the batteries are in the container
operates on the external power source. If you unplug the external
button to make the device operate on the batteries.
3
Press the «IR» button (8) to turn the main IR-illuminator
press and hold the «+» (9) or (10) buttons to increase or
The use of the IR-illuminator in the optimal mode prolongs
image by rotating the objective (4) and the
the operating modes of the IR-illuminator. Do not rotate the
5x42's video-output jack (12) to transmit the image observed to an
and the external power source is turned
power source, you have to press the «ON»
