ASSEMBL OF THE FRONT SHOCK STAY
Y
7
Step 1
3x10mm
Hex Screw
..........X2
503303
Body Post
4x10mm
Hex Screw
..........X4
3x25mm
Cap Screw
..........X2
ASSEMBL OF THE KNUCKLE ARMS
Y
8
Step 1
503215
Front C Hub
5x4mm
Set Screw
..........X2
4mm
Nylon Nut
..........X4
Step 3
503213
Knuckle Arm
Bushing
..........X4
2.5x16.8mm
Pin
..........X2
503214
King Pin Screw
..........X4
ASSEMBL OF THE FRONT SUSPENSION ARMS
Y
9
3mm
Nylon Nut
..........X2
4mm
Nylon Nut
..........X2
4x10mm
Set Screw
..........X2
503307
3mm SPL Arm Shaft(Short)
..........X2
503305
4mm SPL Arm Shaft
..........X2
3x25mm
Cap Screw
3x10mm
Hex Screw
503302
7075 CNC Front
503212
Shock Stay
Shock Ball
End Post
Step 2
503446
4mm
Step 4
Nylon Nut
503214
King Pin
Screw
4mm
Nylon Nut
503305
4mm SPL Arm Shaft
- 8 -
Step 2
3x25mm
4x10mm
Cap Screw
Hex Screw
3x10mm
Hex Screw
3x10mm
Hex Screw
051773
8x16x5mm
Ball bearing
500265
CNC Front
Knuckle Arm
(Left)
051773
8x16x5mm
Ball bearing
503304
Universal Joint
(Front)
3mm
Nylon Nut
4x10mm
Set Screw
503306
Front
Lower Arm
3mm
Nylon Nut
Assembly for both right and left side
503218
5mm
Alum. Wheel Hub
4x4mm
Set Screw
051774
2.5x16.8mm
Pin
Assembly for both right and left side
*A 4x10mm set screw is used
to adjust ride-height.
503307
3mm SPL Arm
Shaft(Short)
* Notice the direction.
