4
ASSEMBL OF THE
Y
CENTER
Step 1
051290
4x10mm
Washer
..........X4
3x12mm
Flat Head
Hex Screw
..........X4
051277
4mm
Alum. Cross Pin
..........X2
5
ASSEMBL OF THE FRONT GEAR CASE
Y
Step 1
051920
13x16x0.2mm
Shim
..........X4
051773
8x16mm Ball bearing
..........X2
4x16mm
Hex Screw
..........X2
4x35mm
Hex Screw
..........X2
6
ASSEMBL OF THE FRONT ARMS HOLDER
Y
5x4mm
Set Screw
..........X1
4x12mm
Flat Head
Hex Screw
..........X2
4x16mm
Flat Head
Hex Screw
..........X2
DIFF.
051277
4mm
Alum. Cross Pin
051290
4x10mm
Washer
503202
Diff. Gear
(Small)
051920
13x16x0.2mm
Shim
¡Adjust the backlash
¡with the shims.
5x4mm
Set Screw
503459
Universal Joint
Center (Front/Short)
3x12mm
Flat Head
Step 2
Hex Screw
Step 2
503207
Gear Case
051773
8X16mm
Ball bearing
503441
Small Bevel Gear
4x35mm
051920
Hex Screw
13x16x0.2mm
Shim
4x16mm
Hex Screw
503235
Front Upper arm
Holder (Rear/Plastic)
NB. use only as matched set "A" with"A"
4x16mm
Flat Head
Hex Screw
500284
CNC Front Lower
arm Holder (B Type)
4x12mm
Flat Head
Hex Screw
- 7 -
051956
Diff. Gasket
503207
Gear Case
503300
Front Lower Arm
Holder(Hard-Coated)
Caster angle can
be changed by using
either A or B set.
A
A
and "B" with "B".
Steering
Characteristics
A
Caster
Steering becomes
(High)
milder.
22 degree
B
Caster
Steering response
(Low)
becomes quicker.
20 degree
