Description
The RD3 device is part of ABB's RD3 family of residual current relays and
provides residual current monitoring and protection in compliance with
annex M to the CEI EN 60947-2 standard* and can be used in combination
with all MCBs S200 and moulded-case devices in the Tmax range up to
T5 for industrial plants.
The two output contacts of the RD3 range of residual current relays can
be used for signalling.
*Up to 630A
