TRD0300- MaTRx PHRK Headrest with MAHU, Rev 1.0 International_Layout 1 06/01/2012 12:48 PM Page 2
EN
PHRK Headrest with Multi-Axis Mounting Hardware
The PHRK headrest with mulit-axis mounting hardware provides users with a high
level of adjustablity combined with exceptional comfort and stability. The fully
adjustable pivoting hardware allows a wide range of headrest adjustment for the
end user. Please refer to the Installation Instructions provided (p.2) to complete the
installation of the PHRK headrest.
MAHU MOUNTING HARDWARE KIT:
Figure 1.0
Multi-Axis Mounting Hardware Kit

TOOLS REQUIRED:

Hex Keys: 5
mm
Tape Measure/Ruler
2
, 4 , 2.5 (provided)
mm mm
Power Drill
1/4" (6.8 ) Drill Bit
mm
