ENGLISH
1 Bit
2 Chuck cover
3 Change ring

SPECIFICATIONS

Model
Blows per minute ................................ 2,000 – 3,500
Overall length ............................................... 468 mm
Net weight ....................................................... 3.1 kg
• Due to the continuing program of research and
development, the specifications herein are subject
to change without prior notice.
• Note: Specifications may differ from country to
country.
Power supply
The machine should be connected only to a power
supply of the same voltage as indicated on the
nameplate, and can only be operated on single-phase
AC supply. They are double-insulated in accordance
with European Standard and can, therefore, also be
used from sockets without earth wire.
Safety hints
For your own safety, please refer to enclosed safety
instructions.

ADDITIONAL SAFETY RULES

1. Wear a hard hat (safety helmet), safety glasses
and/or face shield. It is also highly recom-
mended that you wear a dust mask, ear pro-
tectors and thickly padded gloves.
2. Be sure the bit is secured in place before
operation.
3. Under normal operation, the machine is
designed to produce vibration. The screws
can come loose easily, causing a breakdown
or accident. Check tightness of screws care-
fully before operation.
4. In cold weather or when the machine has not
been used for a long time, let the machine
warm up for several minutes by operating it
under no load. This will loosen up the lubrica-
tion. Without proper warm-up, hammering
operation is difficult.
4
Explanation of general view
4 Switch trigger
5 Adjusting dial
5. Always be sure you have a firm footing.
HK0500
6. Hold the machine firmly with both hands.
7. Keep hands away from moving parts.
8. Do not leave the machine running. Operate the
9. Do not point the machine at any one in the
10. When chipping into walls, floors or wherever
11. Do not touch the bit or parts close to the bit
SAVE THESE INSTRUCTIONS.
OPERATING INSTRUCTIONS
Installing or removing bit
Important:
Always be sure that the machine is switched off and
unplugged before installing or removing the bit.
Clean the bit shank before installing the bit. Insert the
bit into the machine.Turn the bit and push it in until it
engages. (Fig. 1)
If the bit cannot be pushed in, remove the bit. Pull the
chuck cover down a couple of times. Then insert the
bit again. Turn the bit and push it in until it engages.
(Fig. 2)
After installing, always make sure that the bit is
securely held in place by trying to pull it out. To
remove the bit, pull the chuck cover down all the way
and pull the bit out. (Fig. 3)
6 Tile
7 Scaling chisel
Be sure no one is below when using the
machine in high locations.
machine only when hand-held.
area when operating. The bit could fly out and
injure someone seriously.
"live" electrical wires may be encountered, DO
NOT TOUCH ANY METAL PARTS OF THE
MACHINE!
Hold the machine by the insulated grasping
surfaces to prevent electric shock if you chip
into a "live" wire.
immediately after operation; they may be
extremely hot and could burn your skin.
