10. Hydraulic diagrams
Recommended settings:
Parameter
Boiler temperature setpoint
Central heating pump start temperature
Buffer tank control
Buffer tank charging start temperature
Buffer tank charging end temperature
Mixing valve 1 control
Max. mixing valve 1 temperature
Mixing valve 1 heating curve
Mixing valve 1 outdoor temperature compensation
Select mixing valve 1 thermostat*
Mixing valve 2 control
Max. mixing valve 2 temperature
Mixing valve 2 heating curve
Mixing valve 2 outdoor temperature compensation
Select mixing valve 2 thermostat*
* if standard room thermostat with ON/OFF contacts is installed instead of ecoSTER TOUCH room temperature controller, set Universal or if the setting is disabled,
no settings are required for the thermostat.
DHW settings
DHW temperature setpoint
DHW pump operation mode
• Disabled
• Priority
• No priority
DHW storage tank hysteresis
DHW disinfection
DHW storage tank nighttime setback
• Enabled
• Decrease value
• Schedule
Circulation pump nighttime setback*
Leader in pellet boilers
Setpoint
80°C
55°C menu > service settings > CH and DHW settings
Enabled
50°C
75°C
CH enabled menu > service settings > mixing valve 1 settings
70°C menu > service settings > mixing valve 1 settings
0.8 – 1.4
ON
ecoSTER T1 menu > service settings > mixing valve 1 settings
Floor heating ON menu > service settings > mixing valve 2 settings
45°C menu > service settings > mixing valve 2 settings
0.3 – 0.8
ON
ecoSTER T1 menu > service settings > mixing valve 2 settings
Platinum Bio ecoMAX 860P User Manual – EN 09.17
MENU
menu > boiler settings
menu > service settings > buffer tank settings
menu > service settings > buffer tank settings
menu > service settings > buffer tank settings
menu > mixing valve 1 settings
menu > mixing valve 1 settings
menu > mixing valve 2 settings
menu > mixing valve 2 settings
