Step 4:
Step 5:
Step 6:
Step 7:
Step 8:
Step 9:
54
Connect the conductor to the lamp
/ luminaire (
terminal.
Connect the phase conductor to con-
necting terminal L.
Connect the neutral conductor to con-
necting terminal N.
Connect the neutral conductor of the
lamp / luminaire (
conductor of the house installation
(see figure on pg. 51) or to connecting
terminal N (see figure on pg. 52).
Secure the HomeMatic flush-mounted
dimmer to the flush-mounted box
using the provided screws. Please
note that the Config button (B) of the
radio actuator must be at the top left
during installation.
Fit the adapter to the rocker.
) at the connecting
) to the neutral
