TECHNISCHE QUELLEN
GELÄUFIGE SCHRAUBEN, GRÖSSENTABELLE
SCHRAUBENART
74 ETEK5 HANDBUCH
ANZAHL
Solenoid Manifold Screw ( M2.5X5 Cap Head Socket)
3
2 Solenoid Screw (2) ( M1.6X16 Phillips Button Head )
Rubber Grip Screw (4), Breech Sensor Covers Screw (2)
6
(6-32UNC x 5/16 Countersunk Socket)
1 Short Feed Neck Screw (10-32UNF x 1/2" Cap Head Socket)
Long Feed Neck Screw (10-32UNF x 5/8" Cap Head Socket)
1
3 Trigger Adjustment Screw (6-32UNC x 3/16" Socket Set Screw)
Trigger Pin Retaining Screw (6-32UNC x1/8" Socket Set Screw)
1
2 OOPS Screw (10-32UNF x 1" Socket Set Screw)
2 Frame Screw (10-32UNF x 3/8" Socket Button Head)
BESCHREIBUNG
