5. Installation

+45 °C
–20 °C
inlet
5. Installati on
5.1

Installation Space Requirements

Securely fasten unit and fuel cartridges when using in
mobile applications.
Do not operate unit if there is danger of explosion.
Unit is not watertight (protection class IP 54). Make
sure that no water can enter.
Make sure when choosing an installation space that the
temperature ranges between –20° C and +45 °C.
The unit requires air from the outside and generates
off-heat that needs to be conducted to the outside.
Please take this into account when considering
possible locations.
The air openings must not be blocked.
Install only in upright position.
It the lid needs to be free so that it can be opened.
Make sure that the device does not exceed the
maximum inclination.
Inclination along the direct axis: 35° (temporary 45°)
Inclination along the quadrature axis: 20° max.
outlet
17
