Y-Hip Strap; Pelvis Harness - R82 Wombat Basic Gebrauchsanweisung

y-Hip strap

GB
The Y-hip strap can be opened and closed by
using the buckles.
Follow the instructions below, with help from
page 16.
* Mount the straps in the belt fittings under the
seat (D).
* Mount the straps (E) in the beltfittings (E) in
the front of the seat.
E and D can be exchanged.
Take care that all the fixations and adjust-
ments are placed and fitted correctly and
check it on a regular basis.

pelVis Harness

GB
Follow the instructions below, with help from
page 16.
* Open the buckles (G).
* Mount the straps (D) in the belt fittings under
the seat (D).
* Place the user on the harness and close the
buckles (G) over the thighs.
Take care that all the fixations and adjust-
ments are placed and fitted correctly and
check it on a regular basis.
D
19
D
E
G
G
B
