CHest belt

GB
The chest belt can be opened and closed by
using the buckles.
Follow the instructions below, with help from
page 16.
* Mount the shoulder straps in the belt fittings
on the upper back. (A)
* Mount the straps in the sides in the belt fittings
on the back (B).
Take care that all the fixations and adjust-
ments are placed and fitted correctly and
check it on a regular basis.

Hip belt

GB
The hip belt can be opened and closed by using
the buckles.
Follow the instructions below, with help from
page 16.
* Mount the straps in the belt fittings under the
seat (D).
Take care that all the fixations and adjust-
ments are placed and fitted correctly and
check it on a regular basis.
