adjustinG seat and
GB
baCk
The angle of the Wombat Upgrade seat is ad-
justable by simply pushing the release handle
(A), located below the seat. Tip away the safety
device (B) before pushing the release handle.
The angle of the Wombat Basic seat is adju-
stable by turning the handle (C), located below
the seat.
Always keep a hand on the backrest to
avoid the seat from tipping too much for-
ward.
Furthermore it is possible to angle the back by
loosen the grip (D) on the back of the chair.
Seat depth (size 1+2):
To minimize the seat depth, push the back for-
ward and adjust the angle. To adjust the back,
loosen the handle (E).
Seat depth (size 3):
Pull the handle under the seat (I) and push the
back forward or backward.
Loosen the handle (J) on the back and adjust
the back as requested.
Back height (size 1+2):
Adjust the back height by loosen the knob (F).
Turn the knob counterclockwise to loosen. Then
I
pull out the knob and the back is adjustable in
height.
Let go of the knob and the wanted back height
will be locked. Turn the knob again - this time,
clockwise, and the lock will be further ensured.
Back height (size 3):
Pull out locking lever (G) and depress the blue
ring (H) to adjust the back height. Adjust the
height to the desired position and release the
blue ring (H). Resecure locking lever (G).
