nOperations after first power-on
Initial Setting of USB FUNCTIONALITY
USB Hub/Type-C function is disabled in shipping condition from the factory and after FACTORY
PRESET for reduced power consumption.
When turning on the monitor for the first time or after FACTORY PRESET, USB FUNCTIONALITY
message is shown, and one of the below 3 settings can be selected.
OFF: USB FUNCTIONALITY continues to be disabled.
AUTO: USB FUNCTIONALITY is used when the monitor power is ON.
ON: USB FUNCTIONALITY is used when the monitor power is ON and OFF.
Touch "<" and ">" keys for setting then touch "MENU/EXIT" key to close the message.
After this Initial Setting, another selection is possible by OSD menu.
Model
Product
Power Supply
Operating Temperature
Humidity
Altitude
Storage Temperature
Humidity
Power Consumption
(Normal operation* /
1
Standby mode* /Off mode)
2
Dimensions* With stand
3
Without stand Approx. 537.7 mm (W) x 46.6 mm
Weight
*1: Factory setting.
*2: When no signal inputs. Time for power management function: Less than 1 min.
*3: Excluding protrusions.
EA242F
LCD MONITOR
AC 100 - 240 V, 1.40 - 0.70 A, 50/60 Hz
5 ~ 35 °C/41 ~ 95 °F
20 ~ 80% (no condensation)
≤ 5000 m
-10 ~ 60 °C/14 ~ 140 °F
10% ~ 85% (no condensation)
118 W
19 W/0.30 W/0.25 W
Approx. 537.7 mm (W) x 250.0 mm
(D) x 336.2 mm - 486.2 mm (H)
21-3/16 inch (W) x 9-13/16 inch
(D) x 13-1/4 inch - 19-1/8 inch (H)
(D) x 319.1 mm (H)
21-3/16 inch (W) x 1-13/16 inch
(D) x 12-9/16 inch (H)
Approx. 4.5 kg (9.9 lbs)
(monitor only)
Approx. 7.0 kg (15.4 lbs)
(with the stand attached)
English-12
EA272F
Approx. 610.2 mm (W) x 250.0 mm
(D) x 376.9 mm - 526.9 mm (H)
24 inch (W) x 9-13/16 inch (D) x
14-13/16 inch - 20-3/4 inch (H)
Approx. 610.2 mm (W) x 46.6 mm
(D) x 359.8 mm (H)
24 inch (W) x 1-13/16 inch (D) x
14-3/16 inch (H)
Approx. 5.8 kg (12.8 lbs)
(monitor only)
Approx. 9.2 kg (20.3 lbs)
(with the stand attached)
EN
