4. Put the spool into the spool housing.
5. Install the spool cover onto the trimmer head.
6. Push the spool cover until it clicks into position.
5.4 INSTALL THE CUTTING LINE
Figure 14 - 16.
Do not put more than 32.8 feet of cutting line in at a
time.
1. Remove the remaining cutting line on the spool.
2. Line up the slots on the spool cover with the slots
on the trimmer head.
3. Put the cutting line through the hole. Push the
cutting line until it exits the opposite hole.
4. Pull the cutting line through until there is an equal
quantity of cutting line on each side.
5. Turn the spool cover clock-wise to wind
the cutting line into the trimmer head. Keep
approximately 5 in of cutting line on each side of
the trimmer head.
5.5 REMOVE THE TRIMMER HEAD
Figure 17 - 18.
1. Put the metal rod in the specified angle
transmission hole to fix the trimmer head.
2. Turn the trimmer head clockwise to loosen it. Do
not remove the spacer from the shaft.
5.6 ASSEMBLE THE TRIMMER HEAD
Figure 17 - 18.
1. Put the metal rod in the specified angle
transmission hole to fix the trimmer head.
2. Assemble the trimmer head.
3. Turn the trimmer head counterclockwise to
tighten it.
4. Remove the metal rod.
IMPORTANT
You must install the cut-off blade when you use the
trimmer head.
5.7 REMOVE THE BRUSH CUTTER
Figure 19 - 20.
WARNING
Apply the guard to the blade.
1. Put the meatal rod in the specified angle
transmission hole to fix the trimmer head.
English
NOTE
2. Loosen the nut clockwise and remove the outer
cup.
3. Remove the plate and brush-cutter blade.
4. Remove the inner cup.
5.8 ASSEMBLE THE BRUSH CUTTER
Figure 19 - 20.
Wear gloves and be careful with sharp edges.
Apply the guard to the blade.
Use the specified Nylon locknut which is packed with
the blade, to assemble the blade.
1. Put the metal rod in the specified angle
transmission hole to fix the trimmer head.
2. Put the inner cup onto the center shaft.
3. Put the brush-cutter blade on top of the inner
cup.Make sure the blade is in the center.
4. Put the plate above the blade.
5. Put the outer cup above the plate.
6. Put the locknut above the outer cup.
7. Tighten the lock-nut counter-clockwise with the
wrench.
6 TRANSPORTATION AND STORAGE
6.1 MOVE THE MACHINE
When you move the machine, you must:
• Wear gloves.
• Stop the machine.
• Remove the battery pack.
• Assemble the blade guard.
6.2 STORE THE MACHINE
• Remove the battery pack from the machine and
charge it.
• Make sure that children cannot come near the
machine.
• Keep the machine away from corrosive agents such
as garden chemicals and de-icing salts.
• Secure the machine during transportation to prevent
damage or injury. Clean and examine the machine
for any damage.
