1 DESCRIPTION
1.1 PURPOSE
This machine is used to cut grass, light weeds, and
other similar vegetation at or around ground level. The
cutting plane must be approximately parallel to the
ground surface. You cannot use the machine to cut or
chop hedges, shrubs, bushes, flowers and compost.
1.2 OVERVIEW
Figure 1 - 20.
Rear handle
1
Trigger
2
Lock-out lever
3
Speed switch
4
Carrying ring
5
Auxiliary handle
6
Upper shaft
7
Coupler
8
Lower shaft
9
Trimmer head
10
Cut-off blade
11
Guard
12
Knob
13
Release button
14
Positioning hole
15
Bolt
16
Lower clamp
17
Knob
18
Battery release button
19
Tab
20
Spool cover
21
Spool housing
22
Spool
23
Line exit hole
24
Bump knob
25
Angle transmission hole
26
Metal rod
27
Blade
28
Inner cup
29
Plate
30
Outer cup
31
Nut
32
Direction of roatation
A
Best cutting area
B
Dangerous cutting area
C
English
2 GENERAL POWER TOOL SAFETY
WARNINGS
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to
your mains-operated (corded) power tool or battery-
operated (cordless) power tool.
3 INSTALLATION
3.1 UNPACK THE MACHINE
Make sure that you correctly assemble the machine
before use.
• If parts of the machine are damaged, do not use
the machine.
• If parts are missing, do not operate the machine.
• If parts are damaged or missing, contact the
service center.
1. Open the package.
2. Read the documentation provided in the box.
3. Remove all the unassembled parts from the box.
4. Remove the machine from the box.
5. Discard the box and packing material in
compliance with local regulations.
For your personal safety, do not insert battery before
the tool is assembled completely.
3.2 ATTACH THE GUARD
Figure 2.
Do not touch the cut-off blade.
1. Remove the screws from the trimmer head with a
Phillips head screwdriver (not included).
2. Put the guard onto the trimmer head.
3. Align the screw holes on the guard with the screw
holes on the trimmer head.
4. Tighten the screws.
