Power Battery Master
Unpack box and check the content for completeness according to Fig. 3-2.1.
Inspect the Power Battery Master for visible damages.
Contact your supplier, if the delivery is incomplete or damaged.
Do not install, connect and operate the Power Battery Master, if any damage is detected.
1
Fig. 3-2.1 Delivery contents of Power Battery Master
Item Description
1 1x Power Battery Master
2 1x Wall bracket used to fix the upper part of the battery onto the wall
3 2x Handle
4 1x Floor plate (adjustable)
5 1x Manual Power Battery (this document)
1x Accessory packaging with:
- 1x PV-Stick + (Weidmüller)
- 1x PV-Stick - (Weidmüller)
6
- 1x Terminating resistor (RJ 45)
- 1x Patch cable RJ 45/Cat5e 5m
- 1x Ring terminal (for 6mm² cable) for grounding
2 3 4
7
5 6
