Label
PSU status LED
Fan status LED
Figure 7. Module LEDs
1. Port locator beacon LED
2. Port link/activity LED
3. Module locator beacon LED
4. Module status LED
NOTE: The downward and upward pointing triangles denote the lower and upper
port LEDs respectively.
LED Color/Display
• Green solid
• Off
• Green solid
• Off
Description
• Switch in Stacking
Member mode
• Normal operation
• Power not present
• Normal operation
• Power not present
