4.1. Placing the cartridge in the pressure tank
• Remove the pressure tank cover. For this purpose, fix den the pressure tank (place both feet on the
black treads on the base of the pressure tank). Press the locking button (inscription "PRESS AND
OPEN") and turn the cover counterclockwise
• Place the cartridge in the pressure tank. Remove the red cover from the cartridge. You can use it for
transport of a used cartridge.
• Check the O-ring gasket of the cartridge for correct fit.
• Replace the cover on the pressure tank. For this purpose, fix den the pressure tank (place both feet on
the black treads) and put on the cover. The protruding arrow mark must be situated exactly above the
arrow of the "INSERT" groove. Press down the cover and turn it clockwise (inscription "CLOSE"),until
the locking button locks into place.
Mounting instructions BINDER Pure Aqua Service (E2) 07/2022
Figure 4: Removing the pressure tank cover
Figure 5: Installing the pressure tank cover
