Waterproof and Mount Your Router
1. Connect the cables
(1) Detach the waterproof cover (use a
screwdriver if necessary).
(2) Insert a nano SIM card into the slot until
you hear a click.
(3) Fit an Ethernet cable and/or a power cord
as needed for your network.
(4) Lead the cable(s) through the waterproof
rubber and cover.
(5) Reattach the waterproof cover.
2. Choose a method to mount the outdoor router
Notes:
1. For some routers, you need to install the antennas manually first.
2. Ensure your outdoor router is installed upright for better waterproofing.
3. The outdoor router shall be installed in the position with lightning and ESD protection.
4. When selecting a mounting site, make sure the network signal LED is solid green or yellow,
or shows 2 to 3 bars for better internet connectivity.
■ Mounting the Outdoor Router on a Pole
At the selected site, attach the device to a suitable point of the pole and
then approximately align the outdoor router to the direction that you have
oriented.
OR
7
English
Ethernet Cable
Power Cord
(for certain products)
SIM Card
Waterproof Cover
Waterproof Rubber
OR
Ethernet Cable
SIM Card
Waterproof Rubber
Waterproof Cover
