This combination (Fig. 13) does noT
match and can destroy the LED strip.
Both plus terminals (1+5) and
R-terminals (3 + 7) match, but
B-terminal (2) is connected to the
G-terminal (6) and the G-terminal (4)
to the B-terminal (8).
14.
Close the clips tightly to lock the
connection. You will hear a click sound
(Fig. 14).
