X4-Life ED-STREIFEN VERBINDER SET Bedienungsanleitung Seite 30

7.
Always take care of the correct polarity
of the contacts to avoid any defects or
terminal damage. (Fig. 8)
8.
Use the guide bar to push the cut off
segment of the LED strip against the
contacts up to the stop. In this way, the
original length of the LED strip can be
restored.
9.
For a corner connection, use the guide
bar to push the corner connector against
the contacts up to the stop. (Fig. 9)
30
fig. 8
fig. 9
