OPERATING INSTRUCTIONS

Function
mode
selection
Programming
power mode
● Use the left and right keys on the control panel to switch
between options, and press the OK key to enter.
You can select either adjustable mode or fixed mode.
●
●
When you need to adjust the programming voltage, select the
adjustable mode. Use the left and right keys to increase or
decrease the voltage. Once the desired voltage is set, press
the OK key to proceed to the next step.
● In fixed mode, The voltage output is limited to 14V, and the
maximum current output is 120A.
In both adjustable and fixed modes, the maximum current
●
output is 120A, which can be maintained for approximately 3
minutes. If the internal temperature rises to 70°C, the maxi-
mum current output will be limited to 50A. Once the internal
temperature drops to 50°C, the maximum current output will be
restored to 120A.
Fast Charging
Adjustable
Mode
Programmable
Power Supply
Fast Charging
Programmable
Power Supply
Settings
Fixed
Mode
19
Settings
1. Please ensure the battery clamps are
connected correctly: red wire to +,
black wire to -.
2. Please confirm that the 12V battery
has sufficient capacity.
Voltage adjustment range
10.8~16V
