MONTAGEANWEISUNGEN • CONSTRUCTION INSTRUCTIONS
5.1 • Step 7: fitting the beams
1 • Disassemble the sections by removing the upper cylindrical screws (Allen key 3) (DETAIL A & B).
➀
2 • Slide the core of the beams onto the respective shank
➂
Centre the wheels on the bearing surface of the beam
3 • Position the end with U-bracket
4 • Always lock the side beams at the top with two screws with hexagonal socket and flat head .
For a middle beam: use four screws with hexagonal socket and flat head (Allen key 4) (DETAIL C & D).
DETAIL A
DETAIL C
➁
.
w w w r e n s o n
➁
of the end covers of the Rooffix (DETAIL C & D).
➃
when sliding the core
➄ above the mounting bracket ➅
M
➀
J
.
e u
Lagune
S U N P R OT E C T IO N -S C R E E N S
M
➀
on the shank
located in the water channel of the front beam (DETAIL E & F).
J
J
➁
➂
➃
