Solix Fix exterior roller blinds
Setting instructions for bi-directional radio-controlled motors
3.7 Unpairing a radio transmitter
DE
i
Only radio transmitter b can be unpaired.
Option 1
1. When using hand-held radio transmitters, remove the cover on the back to make
your adjustments.
Caution: Press down gently on the battery to keep it in place
(making contact).
After making your adjustments, slide the cover back on.
2. Press the P2 button on radio transmitter a once
=> The roller blind confirms this button press by beeping
+ moving briefly once.
3. Press the P2 button on radio transmitter a once
=> The roller blind confirms this button press by beeping
+ moving briefly once.
FR
4. Press the P2 button on radio transmitter b once
=> The roller blind confirms this button press by moving
briefly twice + beeping three times
Option 2
1. Press and hold the setting button on the drive for approx. 2 seconds.
NL
=> The roller blind confirms this button press by moving briefly and with
a long beep.
2. Press the STOP button on the radio transmitter for approx. 2 seconds.
=> The roller blind confirms this button press by moving briefly twice +
beeping three times
3.8 Resetting to factory settings without a radio remote control
Deletes all settings and all taught-in radio transmitters
1. Press and hold the setting button on the drive.
=> The roller blind confirms this button press by
moving briefly four times at intervals of approx.
EN
4 seconds + beeping four times when the setting
button is released.
=> To reprogram, see step 3.1.
A setting button
B emergency charging socket for charging the battery
3.9 Limiting the number of channels
transmitters)
These settings can be used to limit the radio transmitter to how many channels
i
are actually needed to control the drives. Select channel "0" to control all blinds.
1. Press the P1- and P1+ buttons on the
radio transmitter simultaneously.
ES
=> "C" appears on the LCD display unit.
2. Press and hold the P1- and P1+ buttons on the
radio transmitter.
=> "15" appears on the LCD display unit.
48
IT
a
a
P2
P2
a
a
P2 P2
P2 P2
b
P2
P2
+
b b
a a
A
B
(
only applies to 15-channel radio
C
P1+
C
P1–
P1– P1+
15
15
2
2
3. Press the P1- or P1+ button on the radio transmitter
to select the number of channels. If you will only
control two drives with this radio transmitter, for
example, select "2".
4. Press the STOP button on the radio transmitter once.
=> " " appears on the LCD display unit.
5. "2" will appear after a short time to indicate that the
channels are limited to two.
.
i If you want to deactivate the "Limiting the number of channels" extra function,
repeat steps 1. to 5., increasing the number you select in step 3 to "15".
4.1 Increasing the motor speed/activating slow end position stop
operating mode
1. Press the P2 button on the radio transmitter once
=> The roller blind confirms this button press by beeping +
moving briefly once.
2. Press the UP button on the radio transmitter once
=> The roller blind confirms this button press by beeping +
moving briefly once.
3. Press the UP button on the radio transmitter once
=> The roller blind confirms this button press by beeping once
+ moving briefly twice.
The speed has been increased.
When the max. speed has been reached, the motor then confirms
this by moving briefly and with a long beep.
Slow end position stop operating mode has been set.
Speeds 20 rpm, 24 rpm and 28 rpm.
Factory settings 28 rpm.
(Slow end position stop operating mode only available after end position
programming)
4.2 Reducing the motor speed/deactivating slow end position stop
operating mode
1. Press the P2 button on the radio transmitter once
=> The roller blind confirms this button press by beeping
+ moving briefly once.
2. Press the DOWN button on the radio transmitter once
=> The roller blind confirms this button press by beeping
+ moving briefly once.
3. Press the DOWN button on the radio transmitter once
=> The roller blind confirms this button press by beeping once
+ moving briefly twice.
The speed has been reduced.
When the min. speed has been reached, the motor then confirms
this by moving briefly and with a short beep.
Slow end position stop operating mode has been deactivated.
Subject to technical changes I
C
P1+
C
P1–
P1– P1+
15
15
2
2
P1– P1+
2
2
P2
P2
Edition 10.2024
