Important safety information for users
i
Information on the battery-operated radio drive
– Protect the exterior roller blind/radio drive from knocks during transpor-
tation, storage and installation.
– Use only the charger approved by MHZ.
– The rechargeable battery is shipped partially charged.
– Prior to installation and first use, the battery must be fully charged (takes
approx. 6 hours).
– In subsequent operation, the time required to charge the battery when
fully discharged is approx. 3 hours.
– The red LED on the charger lights up when the charger is plugged in
and indicates that charging is in progress. The battery is fully charged as
soon as the green LED comes on.
– The rechargeable battery and the radio drive are fitted as one unit in-
side the roller blind tube. A defective battery can only be removed and
disposed of together with the radio drive.
– Remote control range in enclosed buildings: approx. 20 m.
– The setting of the end positions is retained even when the battery has
discharged.
– Radio drive and control system components are not compatible with
other manufacturers' products.
– No synchronous running when using group control.
– When operating the roller blind at temperatures below or around free-
zing point, the blind may take a little longer to start moving.
– The drive indicates that the battery charge level is low by emitting sever-
al beeps each time the blind moves. The battery should be charged
immediately to ensure the unit will keep working without disruption.
– When the roller blind stops because the battery does not have
sufficient capacity, it is not yet in the range of a total discharge.
However, it should be charged as soon as possible to prevent a
total discharge.
– For the solar panel to work perfectly, it should be exposed to direct
incident sunlight and cleaned at regular intervals (at least once a
year, ideally before winter starts) with a damp cloth (lukewarm wa-
ter). If this is not done, the battery may need to be topped up using
the charger during the darker months to prevent a total discharge.
i
Technical data
A tubular motor with a built-in rechargeable battery is permanently
installed in the fabric tube around which the exterior roller blind is
wound. This motor can be replaced if necessary. The unit must be sent
to the manufacturer via the specialist retailer for this replacement to be
carried out.
Motor: 12 V DC / 1.1 Nm / 1.0 A / 12 W
Rechargeable battery: Li-ion/2200 mAh
Temperature range: -10°C to +75°C
Edition 10.2024
Subject to technical changes I
Operating instructions
Information on charging the battery
Caution! Risk of falling from climbing aid!
You must use a safe climbing aid to charge the battery in an elevated
position. Always place the climbing aid on level, load-bearing ground.
Observe the maximum load-bearing capacity.
Do not lean the climbing aid against the product.
The climbing aid could tip over if it is positioned or loaded incorrectly.
i
Charging the battery
Information on disposal
This device falls under EC Directive 2002/96/EC, which aims
to reduce the ever-increasing amount of waste electrical
and electronic equipment that is being created and to
dispose of such waste in an environmentally friendly manner.
Do not dispose of this device with your normal household waste.
Take the device to the appropriate local authority collection point
to ensure its materials can be recycled and/or disposed of properly.
Disposing of the device in a careless and unregulated way could da-
mage both the environment and human health. By making sure your
product is disposed of and/or recycled responsibly, you are doing
your bit to protect the environment and people's health.
CE product labeling
MHZ Hachtel GmbH & Co. KG
Sindelfinger Strasse 21, D-70771 Leinfelden-Echterdingen, Germany
2021
LE-014
EN 13561: 2004+A1:2008
External roller blind Solix Fix 46-1180
Attachment to the exterior of buildings and
other structures.
Wind resistance* = Class 2
* The declared performance applies only to the product. After installation, the
performance may be lower due to the mounting surface.
Please note "Use in windy conditions"
Solix Fix exterior roller blinds
– The solar panel will usually
supply the unit with enough
power. However, if the power
does need to be topped up,
the battery can be charged
manually using the
emergency charging socket.
– The emergency charging so-
cket is located on the bottom
of the cassette.
– Connect the charger plug to
a power source. Then insert
the charging cable firmly into
the charging socket. The LED
on the charger lights up red.
