3. Maximum capacity: 130 [kg]
4. Braking distance on horizontal surface (on max. speed): ≤1 [m]
5. Range: 20-25 [km]
6. Batery: acid 12[V] x 20 [Ah]
7. Max. angle of eleva�on: ≤ 12°
8. Max. turning radius: 0,85 [m]
9. Wheelchair weight: 28 kg
10. Batery weight: 13 kg
Note! Some parameters might vary depending on user weight, road condi�ons
and batery usage.
• Safety Classifica�on: type B
• Ingress protec�on level for engine: IP33
• Engine power level: around 250[W] for right and le� engine
• Wheelchair cannot be used in area with flammable gas mixed with air,
oxygen or nitrous oxide.
3. Icon descrip�on
Symbol
IP33
4. Assembly and adjustment
• Take out electric wheelchair from a box. Using push handles, unfold the
wheelchair and li� up backrest.
Note! Do not catch hinges next to a seat while unfolding wheelchair. There's
risk of ge�ng fingers caught in.
Safety Classification type B
Important! Read the instruction
Protection against access to hazardous parts
with a tool, protection against foreign solids
with a diameter of 2.5 mm and larger,
protection against water spray at any angle
up to 60° from the vertical on each side
Protect from humidity and moisture
Meaning
Fragile
This side up
