EN
Maintenance
Cleaning the lint filter
Ensure the lint filter is in place whenever
drying. It must be cleaned before each use.
1. Removing the filters
There are four holes around the shroud, so
you can insert your fingers. The filter is
made up of three parts: the exhaust vent
shroud, the lint filter and the exhaust filter
(refer to Fig. 1).
The filter fixed in the
bottom of the drum
Exhaust Lint
vent shroud filter
2. Cleaning the filter
Using a soft brush or vacuum cleaner,
clean the lint on the lint filter and exhaust
filter. Be careful not to damage the filters
(refer to Fig. 2).
Lint filter Lints Exhaust Filter
3. Reinstalling the filter
After cleaning, assemble in this order:
exhaust filter, lint filter and exhaust vent
shroud. Align the recesses in the center of
each filter component with the projection in
the center of the drum. Ensure it is firmly
inserted (refer to Fig. 3).
Note: Using a soft brush, clean the
filter fixed at the bottom of the drum.
Exhaust
Filter
Dust Cleaner
Cleaning the air intake filter
Clean the filter at least once a month.
Remove the filter by pulling outwards,
holding the upper and lower ends of the air
intake shroud firmly. Take out the filter from
inside the shroud. Use a soft brush to clean
the filter thoroughly. Place the filter back
inside the shroud, ensuring it is properly
aligned and securely in place.
Slightly push upwards with your thumb -
the latch hook will disconnect, so you can
remove it.
Cleaning the inside and outside of the
dryer
Do not wash directly in water.
Do not use thinner, gasoline or alcohol.
When cleaning the inside, do not use any
type of spray cleaners. To clean stains on
the drum, use a damp cloth.
Before drying the next load, remove any
residue. Clean the cabinet with mild soap
and water. Do not use harsh or abrasive
cleaners - this could damage the dryer.
WARNING:Regularly clean
the lint trap
CAUTION! HOT SURFACE
Do not touch the intake during the
drying cycle due to high temperatures
READ THE INSTRUCTIONS
12
Air Intake Shroud
Air Intake Filter
