The LEDs, located at the base of each PowerCel charging port, have 3 color options.
Color
Blue
Green
Red
*Try to reinsert the PowerCel and if the red LED illuminates again, contact your
implant center.
There is a rare condition where the PowerCel port LED turns off (or may show a faint
blue if the room is very dark). This LED off behavior indicates either a fully charged
battery or battery with an error condition. The user should wait at least 1 full minute,
if the LED does not turn green, then the battery should be considered as having an
error and the user should contact Advanced Bionics for a replacement. If the LED
turns green, then the battery is fully charged and ready for use.
Assembling the PowerCel Charger
The charging system consists of the charger, power supply and power adapters.
The charger can also be used with the power supply removed from the cable,
exposing the USB jack so it can be powered from any USB port.
4
Indication
PowerCel is charging
PowerCel fully charged
Fault condition*
