CONNECT THE CHARGER TO A BATTERY
Comfort
Connect
+
Comfort
Connect
ort
6 • EN
ect
INFO
If the battery clamps are incorrectly
connected, the reverse polarity
protection will ensure that the battery
and charger are not damaged.
For batteries mounted inside a
vehicle
1. Connect the red clamp to the battery's
positive pole.
2. Connect the black clamp to the vehicle
chassis remote from the fuel pipe and
the battery.
–
3. Connect the charger to the wall socket.
4. Disconnect the charger from the wall
–
socket before disconnecting the battery.
5. Disconnect the black clamp before the
+
red clamp.
CHARGING PROGRAMS
Settings are made by pressing the MODE-button. After about two seconds the charger
activates the selected program. The selected program will be restarted next time the
charger is connected.
The table explains the different Charging Programs:
Battery
Program Explanation
Size (Ah)
Normal battery program
20–300Ah
14.4V/10A. Use for WET batteries,
Ca/Ca, MF and for most GEL batteries
AGM battery program 14.7V/10A
AGM 20–300Ah
Use for AGM batteries.
Recond program 15.8V/1.5A
Use to return energy to the empty
WET and Ca/Ca batteries. Recond
20–300Ah
RECOND your battery once per year and after
deep dischare to maximise lifetime and
capacity. The Recond program adds
STEP 6 to the normal battery program.
Supply program 13.6V/10A
Use as 12V power supply or use for
float maintenance charging when 100%
20–300Ah
capacity of the battery is required.
Supply program activates step 7 without
time or voltage limitation.
WARNING!
The spark protection on the battery charger
is disabled during SUPPLY program.
Temp range
-20°C–+50°C
(-4ºF–122ºF)
-20°C–+50°C
(-4ºF–122ºF)
-20°C–+50°C
(-4ºF–122ºF)
-20°C–+50°C
(-4ºF–122ºF)
