(329IO) MODEL ECO5220/5230 & 6220/6230 SALTWATER SYSTEM WITH E.C.O. ENGLISH 7.5" X 10.3" PANTONE 295U 05/23/2024
Before assembling your product, please take a few minutes to check the contents
10
14
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
REF. NO.
PARTS FOR
COMMON CONNECTION
PARTS TO FILTER PUMPS WITH
1-1/4" (32MM) HOSE SIZE
1 ADAPTOR A WITH THREADED COLLAR
2 SCREW
3 ELECTROLYTIC CELL HOUSING
4 SECONDARY ELECTROLYTIC CELL
5 PRIMARY ELECTROLYTIC CELL
6 FLOW SENSOR
CONNECTOR HOSE WITH THREADED FITTINGS
7
8
THREADED ADAPTOR B
CELL COVER
9
10 ELECTROLYTIC CELL NUT
11 L-SHAPE O-RING
12 TITANIUM ELECTRODE O-RING
13 CONTROL STATION
14 TEST STRIPS
15 TITANIUM ELECTRODE O-RING
16 ELECTROLYTIC CELL NUT
When ordering parts, be sure to quote the model number and part numbers.
SAVE THESE INSTRUCTIONS
PARTS REFERENCE
and become familiar with all the parts.
6
1
11
3
5
12
9
DESCRIPTION
English
8
7
2
15
16
4
13
SPARE PART NO.
QTY.
ECO5220/5230 ECO6220/6230
1 10849 10849
2 11519 11519
1 11898 11903
1 11900 11905
1 11899 11904
1 11460 11460
1 10720 10720
1 10722 10722
2 11131 11131
1 11582 11432
2 11228 11228
1 11585 11515
1 12658 12660
1 19635 19635
1 11585 11585
1 11582 11582
Page 4
