PREMIUM version

Note: The commeo Multi Send is supplied in the BASIS version. You can only use the PREMI-
UM version after purchasing an upgrade (see section 4.3.).

16. Device description

16.1. Description of the commeo Multi Send – PREMIUM version
1
2
3
4
5
6
7
8
9
1 Display
2 Display button right
3 Display button left
4 Status LED
5 UP button
6 Left channel selection button
7 STOP button
8 Right channel selection button
9 DOWN button
10 Micro-USB port
11 Programming button/PROG.
12 Select button/SELECT
13 2 x AAA batteries (inside)
14 Retention screw for battery compartment
Front side
130
10
11
12
13
14
Rear side
