E
F
G
H
7. Replace the used LED illuminant by a new one of the same type and power.
a. ILCOS D-Code for this illuminant: DBS-2/65-H-120/33.
b. LED module - rectangular lamp.
c. Max. Wattage: 1*2.0 W.
d. Rectangular lamp: dimensions W*D in mm = 120.00 ± 1.00*33.00 ± 0.50.
8. To reinstall the LED illuminant, please proceed in reverse order.
I
LLUMINANT CONNECTION CABLE
S
PRING CLIPS
Required minimum distance to surfaces such as pot lids, oven
cloths etc. to avoid any hot parts and risk of fire.
(4 pcs. in total)
S
ECURING PLATE
I
LLUMINANT HOLDER
65
