Wall mounting：
1. Drill two holes on the wall by using the base of the camera as a template. It
is recommended that you mark the locations of the hole with a pencil before
drilling. The drilling diameter should be around 6.0 mm with a depth of
around 30 mm.
2. Insert the two plastic anchors into the holes on the wall. Make sure to
position the base unit so that the arrow is pointing up. Secure the base unit in
place by tightening the screws into the plastic anchors.
3. Align the groove at the bottom of the camera with the raised part on the
base, snap it in and rotate it in the direction shown below until locked in place.
Notes on wall mounting:
1. The wall on which the device is mounted must have a loading capacity
of at least 3 times the weight of the device.
2. To avoid any damages or injuries, the device must be securely fastened
to the floor/wall as specified in the installation instructions.
