ASSEMBLY (IP1000 SERIES)
1. Slide the Wand onto the neck of the Floor
Nozzle until it clicks into place�
2. Align the Hand Vacuum nozzle opening
with the top of the wand and slide it on
until it clicks into place�
Handheld
Vacuum
2.
(Click)
Flex Wand
1.
(Click)
6
sha rkclean.eu
For proper operation, ensure all components
are completely connected and clicked
into place�
Floor Nozzle
CHARGING YOUR LI-ION BATTERY
Prior to first use, charge the battery completely� A full charge takes approximately 6 hours�
RUNTIMES PER FULLY CHARGED BATTERY
With a full charge, the unit will have up to a 70-minute runtime� Visit sharkclean.eu online for
more information�
LED BATTERY POWER AND CHARGING INDICATORS
Charging
LED on the battery pack will pulse yellow when reaching 0-75% charge.
LED on the battery pack will pulse green from 75% - 100% charge.
White LED the battery pack is fully charged.
NOTE: Full charge takes approximately 6 hours.
Additional Notes
1� LEDs turn off once the battery is fully charged�
2� Unit will not power on when charger is connected�
In Use
Full
Mid
Charge
Charge
RECYCLING THE LI-ION BATTERY
When the Shark Li-ion battery needs to be replaced, dispose of it or recycle it in accordance
with local ordinances or regulations� In some areas, it is illegal to place spent lithium-ion
batteries in the standard rubbish bin� Return spent batteries to an authorised recycling centre
or to the retailer for recycling� Contact your local recycling centre for information on where to
drop off the spent battery�
NOTE: The Shark battery, like all lithium-ion batteries, will naturally decrease in capacity over time from the 100% capacity of
a new battery�
NOTE: Battery consumption will vary depending on the
mode being used:
ECO – Maximum Runtime, saves battery power
AUTO – Optimises suction and power for maximum
cleaning
BOOST – Maximises suction� Uses the most batter power
Low
No
Charge
Charge
s ha rkc lea n.eu
7
