2.
Remove insulation sleeve 10mm for six conductors. And shorten
phase L and neutral conductor N 3mm.
3.
Insert AC input wires according to polarities indicated on terminal block
and tighten the terminal screws. Be sure to connect PE protective
conductor (
→Ground (yellow-green) L→LINE (brown or black) N→Neutral (blue)
WARNING:
Be sure that AC power source is disconnected before
attempting to hardwire it to the unit.
4.
Then, insert AC output wires according to polarities indicated on
terminal block and tighten terminal screws. Be sure to connect PE
protective conductor (
→Ground (yellow-green)
L→LINE (brown or black)
N→Neutral (blue)
)first.
)first.
- 9 -
