EN
Applicable documents
Download at www.baumer.com:
◼
▪ Data sheet
▪ EU declaration of conformity
As a product insert:
◼
▪ General information insert (11042373)
Function principle
The sensor is used for pressure measurement.
The measured pressure is output as an electrical
signal.
General information
The sensor must not be exposed to strong
◼
impacts.
Do not exceed the static or dynamic overload
◼
limits specified in the data sheet.
Do not remove the protective cap until
◼
mounting the sensor.
Retain the protective cap for any later storage
◼
or transport.
Do not clean the membrane using abrasive
◼
agents.
Do not touch the membrane with solid bodies
◼
(neither use finger).
Safety instructions
This sensor has been assembled, tested and
◼
packed under technically safe conditions
according to currently applicable EU directives.
To maintain and ensure safe operation, observe
the information and warnings in this manual.
For installation observe and comply with the
◼
nationally applicable standards.
Sensor operation only by instructed and
◼
qualified
personnel.
Correct
and
deployment depends on proper transportation,
storage, installation and operation of the
product.
Wiring work and terminal assignment must
◼
comply with the electrical connection diagram.
Prior to power off ensure that no other parts of
◼
the installation will be implicated.
Make sure supply voltage and the ambient
◼
condi-tions
comply
with
the
specifications.
Prior to power off, check potential effects on
◼
other system components or installations.
WARNING
Destruction of the device by excessive
pressure!
Exceeding the burst pressure, even shortly, may
destroy the device..
a) Avoid any excessive pressure by taking the
appro-priate actions (see data sheet).
▪
Ensure that both pressure and nature of the
fluid to be measured are compatible with the
sensor. The fluid must be compatible with
stainless steel 1.4404 (AISI 316L) resp. 1.4301
(AISI 304), ceramic 96% AL2O3 as well as with
the nature of the seal.
▪
Only use the sensor in fluids it is intended for.
Prior
to
commissioning,
measuring fluid does not require material for
potentially explosive atmospheres. Mounting a
non-intrinsically
safe
sensor
prohibited for such fluids
The fluid must not freeze inside the sensor. Do
▪
not insert any rigid elements into the opening of
the pressure connection, since they may
destroy the diaphragm.
The mounting position has no influence on the
▪
measuring
operation.
protecting
the
device
environmental impacts such as pressure
pulsation, water hammer, vibration, shocks,
heat sources, electric and magnetic fields,
lightning, humidity and bad weather.
Make sure the connection is tight. The sealing
▪
surface must be clean and use an appropriate
gasket.
When mounting the sensor please ensure that
▪
the four filter holes around the sensor body are
safe
not directly exposed to continuous liquid drops,
i.e. oil or water. Otherwise, the filters will
eventually block.
product
Installation instruction of PP20R
DANGER
Risk of injury from dangerous and hot media
The sensor housing can heat up to over 50 °C
during operation
a) Wear suitable and protective gear when
working with hazardous and/or hot media (e.g.
acids, lye).
b) Empty pipes prior to the installation.
Use Teflon tape (PTFE) for sealing the threads of
sensors with the following process connections
using a torque of max. 40 Nm:
1/4 NPT (BCID N02)
◼
make sure the
G 1/4 B EN 837-1 (BCID G30)
◼
G 1/2 B EN 837-1 (BCID G31)
◼
is
strictly
Do not use Teflon tape (PTFE) for sealing the
threads of sensors with the following process
connections using a torque of max. 40 Nm:
G 1/4 A DIN EN ISO 1179-2 / DIN 3852-E (BCID G50)
◼
G 1/2 A DIN EN ISO 1179-2 / DIN 3852-E (BCID G51)
◼
G 3/4 A DIN EN ISO 1179-2 / DIN 3852-E (BCID G57)
◼
We
recommend
Installation compliant to UL certification
against
strong
The appliance is only certified for indoor use. UL
does not evaluate IP protection classes.
Device power supply must be provided by external
circuits in accordance with Class III as well as low
voltage in accordance with clause 9.4 of UL/CSA
61010-1 3rd ed. or Class 2 of UL1310.
Mandatory to use UL-approved CYJV/7 or PVVA/7
cables with voltage, current and temperature
ratings suitable for the application, but minimum
130 °C. If the device is used otherwise than
specified by the manufacturer, the device-specific
protection ratings may be impaired.
Maintenance
The sensor is maintenance-free. No special
preventive maintenance is required. Regular
cleaning and inspection of connection and seal
are recommended.
