Set TX internal:
prm = {1 ~ 7}
1: 1080P60Hz
2: 4K60Hz
3: 4K30Hz
4: 4K25Hz
5: 4K24Hz
6: 720P60Hz
7: 480P60Hz
prm2 = {1 ~ 12}
1: Black
2: Checkboard
3: Strip
4: Red
5: Green
6: Blue
7: White
8: Ramp
9: Red ramp
10: Green ramp
11: Blue ramp
12: PRBS
Get TX internal
HDCP Information:
Description
Set HDCP status of the TX input
prm = { 0 ~ 2}
0 = HDCP aus
1 = HDCP 1.4
2 = HDCP 2.2
Get HDCP status of the TX input
Set HDCP status of the TX output
prm = {0 ~4}
0 = Reserved
1 = Follow the sink
2 = Follow the source
3 = Force HDCP 1.4
4 = Force HDCP 2.2
Get HDCP status of the TX output
EN
SET TX PATTERN prm1
prm2<CR><LF>
GET TX PATTERN<CR><LF>
Command
SET TX INPUT
HDCP
prm<CR><LF>
GET TX INPUT
HDCP<CR><LF>
SET TX OUTPUT
HDCP
prm<CR><LF>
Get TX OUTPUT
HDCP<CR><LF>
Set TX pattern 1080P60Hz
checkboard
TX pattern 1080P60Hz checkboard
Example of feedback
Set TX input HDCP 2.2
TX input HDCP 2.2
Set TX Output HDCP to follow sink
Follow sink
