EDID:
Beschreibung
Setze TX EDID
prm = {0 ~ 18}
0: EDID des RX HDMI Ausgangs kopieren (default)
1: 1920x1080p60Hz, Audio 2CH PCM
2: 1920x1080p60Hz, Audio 5.1CH DTS/DOLBY
3: 1920x1080p60Hz, Audio 7.1CH DTS/DOLBY/HD
4: 3840x2160p30Hz 4:4:4, Audio 2CH PCM
5: 3840x2160p30Hz 4:4:4, Audio 5.1CH DTS/DOLBY
6: 3840x2160p30Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
7: 3840x2160p60Hz 4:2:0, Audio 2CH PCM
8: 3840x2160p60Hz 4:2:0, Audio 5.1CH DTS/DOLBY
9: 3840x2160p60Hz 4:2:0, Audio 7.1CH DTS/DOLBY/HD
10: 3840x2160p60Hz 4:4:4, Audio 2CH PCM
11: 3840x2160p60Hz 4:4:4, Audio 5.1CH DTS/DOLBY
12: 3840x2160p60Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
13: WUXGA 1920x1200p 60Hz, Audio 2CH PCM
14: DVI 1280x1024p60Hz, Audio None
15: DVI 1920x1080p60Hz, Audio None
16: DVI 1920x1200p60Hz, Audio None
17: User Defined 1
18: User Defined 2
Hole EDID des TX
Hole TX EDID Daten
Schreibe EDID Wert in Custom EDID
prm1 = {0 ~ 2};
0 = User Defined 1 und 2
1 = User Defined 1
2 = User Defined 2
prm2 = EDID in Hex in 256 Bytes
Hole Custom EDID
prm = {0 ~ 2};
0 = User Defined 1 und 2
1 = User Defined 1
2 = User Defined 2
12
Beispiel für
Befehl Rückmeldung
SET TX
Set TX input EDID to
EDID
00_Copy EDID from RX
to prm
HDMI output (default)
<CR><LF>
TX input EDID to
GET TX
EDID 00_Copy EDID from RX
<CR><LF>
HDMI output (default)
GET TX
EDID TX input EDID
DATA <00 FF FF FF...>
<CR><LF>
SET USER
EDID
USER defined 1
prm1
EDID is loaded
<prm2>
<CR><LF>
GET USER
USER defined 1 EDID
EDID prm
<00 FF FF FF...>
<CR><LF>
