5.1 Connecting to Monitor and Power
• Connect the video-out jack to the video-in jack
of the monitor.
• Connect the power adapter to the power input
connector.
• Use VDC
power source
• Use the power rated at least 400mA (VDC)
Function
1
Video output
2
Power input
Terminal Colour
Yellow
Red
Video (yellow)
Power - VDC
(red)
Remark
.0 Vp.p
VDC (9V~5V), max. 4.8W/400mA
43
Video Output
GND
