3. Installation
All manuals and user guides at all-guides.com
Ceiling
Make sure the power is removed before the
installation !
Guide pattern
. Stick the guide pattern on the wall or ceiling.
. Drill four holes according to the the guide pattern,
Rubber
then insert anchors into the drilled holes.
3. Draw out power / video wires to the connecting
places.
Dome base
4. Attach the camera base to the ceiling or wall using
the supplied four screws.
5. Adjust desired focus and scene by turning and
moving the 3-axis camera bracket by hand.
Mounting screw
6. Put the dome cover over the base.
7. Fix the dome cover on the base by L-wrench.
Dome cover
L-Wrench
4
