4. Parts Name and Functions
All manuals and user guides at all-guides.com
Camera Lay-out
1 Tilt rotation
2 Pan rotation
3 Horizontal rotation
4 Focus handle
5 Zoom handle
6 IR LED
Adjusting the vertical angle
Adjusting the horizontal angle
Adjusting the horizontal position of the screen
Focus (Far or Near)
Zoom (Tele or Wide)
850nm / 30° (0EA)
