ELECTRICAL INTERCONNECTION
VEHICLE
BATTERY
4
3
+12V
1
Connect both +12V connections of the 20-pin connector with the +12V pole of the vehicle's battery. Use
a suitable cable with a sufficient cross section (recommended 1.5 mm
12V connections are connected.
Since the DSP amplifier has no internal device fuse due to its design, you must install a 20 A cable fuse
in the +12V power line near the vehicle battery and near the device with a maximum distance of 30 cm.
GND
2
Connect both GND connections of the 20-pin connector with a suitable contact ground point on the ve-
hicle's chassis. The ground wire must be as short as possible and must be connected to a blank metal-
lic point at the vehicle's chassis. Ensure that this ground point has a stable and safe electric connection
to the negative "–"pole of the battery. Use a suitable cable with a sufficient cross section (recommended
1.5 mm
. Please make sure that both GND connections are connected.
2)
REM IN
3
Connect a turn-on signal or the turn-on remote signal of your head unit (REM) with the REM IN termi-
nal. Use therefor a suitable cable with a sufficient cross section (recommended 0.5 mm
device turns on or off with your head unit. If you use the AUTO TURN-ON function (refer to page 24,
section 8), the REM IN terminal does not need to be connected.
REM OUT
4
The REM OUT terminal can be connected with the REM terminal of another device to provide a turn-on
signal (REM OUT function).
< – max. 30 cm– >
20 A
ENGLISH
1
2
. Please make sure that both
2)
). Hereby the
2
23
