Technical Data
Distance measurement
Precision (typical)*
Measurement range (inside)**
Angle measurement
Measuring range
Resolution
Precision
Laser class
Laser wavelength
Operating conditions
Storage conditions
Radio module
operating data
Automatic switch-off
Power supply
Dimensions (W x H x D)
Weight
* measuring distance up to 10 m with strongly reflective target surface
and at room temperature. The measurement deviation may increase by
± 0.2 mm/m for greater distances and under unfavourable measuring
conditions such as strong sunlight or weakly reflective target surfaces.
** at max. 5000 lux
24
EN
(Subject to technical changes without notice. 24W43)
± 2 mm
0.05 m - 70 m
± 90°
0.1°
0.1°
2 < 1 mW
515 nm
-10°C ... 40°C, max. humidity
20 ... 85% rH, no condensation,
max. working altitude 2000 m
above sea level
-20°C ... 70°C,
max. humidity 80% rH
IEEE 802.15.4. LE ≥ 4.x (Digital
Connection) interface; Frequency
band: ISM band 2400–2483.5 MHz,
40 channels; Transmit power: max.
10 mW; Bandwidth: 2 MHz; Bit rate:
1 Mbit/s; Modulation: GFSK / FHSS
30 sec laser / 3 min device
2 x 1.5V LR6 (AA)
50 x 122 x 27 mm
140 g (incl. batteries)
