tfk mono2 combi Gebrauchsanleitung Seite 9

- WARNING Do not allow the child to play with the product.
- WARNING This seat unit is not suitable for children under 6 months.
- WARNING Always use the restraint system.
- WARNING Before use, make sure that the pushchair attachment or
the seat unit or the car seat fasteners are correctly engaged.
- Maximum weight of the child when used in the sitting position: 22 kg.
- DO NOT place the combi unit near an open fire or other sources of heat.
- Do not fit any TFK - foreign accessories!
Please check the brakes and connections for proper function at regular
intervals! In case of repair, only use original spare parts from TFK!
INSTRUCTIONS FOR USE AND ASSEMBLY
Fig. 1: After taking the combi unit out of the box, unfold both joints (1) and
insert the foot stirrup (2) so that the one with the cross strut faces the foot end.
Fig. 2: Position the tub over the pins (3) on the frame struts and push it on until
it audibly clicks into place.
To remove the tub again, hold it with one hand by the carrying/covering
handle (4) and with the other release the lock (5) at the head end of the tub
by turning the release handle. Now remove it upwards. You can put the tub
on in both directions. Also in the sitting position.
Fig. 3: Up to an age of approx. nine months, use the tub exclusively in the
lying position. To improve the lying comfort for your child, unbutton the 5-
point harness and insert the mattress (6).
Fig. 4: You can attach the supplied wind cover (7) with the zip fastener over
the open foot area.
To open the canopy, press the grey button 8) and fold the canopy back. It
locks into three positions.
Fig. 5: The backrest of the tub can be adjusted continuously by pressing the
locking device (9) together and pulling the strap (10) at the same time. You
can attach the end of the strap to the backrest with the Velcro fastener.
