However, it is important for the development of your child that you leave the
lying surface of the tub horizontal for as long as possible.
Fig. 6: If you want to put the tub in the sitting position, remove the mattress
and fasten the 5-point harness (11) and the belly bar (12).
Always secure your child with the 5-point belt. Close the belt by joining the
two parts (13) on the belt straps (left and right) and inserting them into the
belt buckle (14) until they audibly click into place. To open, simply press the
button in the middle of the belt buckle (14). The harness can be adjusted to
the size of your child with the tensioning system and the height lock. To make
it easier to get in, you can hook the straps to the loops (15) on the left and
right.
The belly bar (12) is attached to the frame on the left and right under the
swivel joint. Position it and close the locks (a).
Fig. 7: To swivel the tub into the three different positions, turn the vedr lock
(16) and bring it into the desired position.
ATTENTION: Only swivel the tub without the child! You can use the tub with or
without an additional footrest in the sitting position.
Fig. 8: Attach the additional footrest (17) by snapping the telescopic rod into
the two receptacles provided in the frame. On the back of the foot rest you
can press the two sliders of the telescopic rod together, this makes it easier
to attach and is necessary to remove the footrest. Finally, attach the cover
to the footboard with the press studs (a).
Remove the adhesive dots on the frame, they only serve to identify this
position.
Fig. 9: You can swing an integrated sun visor (18) out of the canopy. For
better ventilation of the tub, you can open the zips (19) at the head end of
the canopy and the tub to provide fresh air. Fold the open covers upwards.
Two magnets at the foot end secure the open flap in this position.
If you do not open the zip of the foot cover completely, you can fold it away
to the side.
