GWARANCJA I SERWIS
Warunki gwarancji oraz opis postępowania w przypadku reklamacji
zawarte są w załączonej Karcie Gwarancyjnej.
Serwis Centralny GTX Service Sp. z o.o. Sp.k.
ul. Pograniczna 2/4 tel. +48 22 364 53 50
02-285 Warszawa e-mail bok@gtxservice.com
Sieć Punktów Serwisowych
pogwarancyjnych dostępna na platformie internetowej gtxservice.
pl
Zeskanuj QR kod i wejdź na gtxservice.pl
TRANSLATION OF
THE ORIGINAL INSTRUCTIONS
DEMOLITION HAMMER
58G878
CAUTION: BEFORE USING THE POWER TOOL READ THIS MANUAL
CAREFULLY AND KEEP IT FOR FUTURE REFERENCE.
DETAILED SAFETY REGULATIONS
PRECAUTIONS FOR USING HAMMER DRILL
Caution: Unplug the power cord from the mains socket before
commencing any activities related to adjustment, repair or maintenance.
• During hammer operation use protective glasses or goggles, ear
protection and protective helmet (when there is danger of falling
objects). The use of a protection half-mask and anti-slip boots is
recommended. Use dust extraction systems whenever required by
the nature of the work performed.
• Prior to operation ensure the drill chuck of the hammer is properly
fixed in place.
• During operation due to vibrations working tool may get loosened.
Check carefully how the working tool is fixed prior to operation.
Unwanted slack may cause tool damage or accident during operation.
• If the hammer is to be operated at low temperature or after long
storage, allow the hammer to operate for few minutes without load,
for its internal elements get properly lubricated.
• When operating the hammer held high, spread your legs on the
ground and ensure there are no bystanders below.
• Always hold the hammer with both hands, use additional handle.
• Do not touch moving parts of the hammer. Do not stop rotating
spindle of the hammer with your hands. Such behaviour can cause
hand injury.
• Do not direct operating hammer at other persons or at yourself.
• When operating the hammer hold it by insulated parts to avoid
electric shock in case of a damage to live electrical wire.
• Do not allow any dust to get inside the hammer. Use mineral soap
and damp cloth to clean hammer surface. Do not use petrol or other
cleaning agents that could damage plastic parts.
• Do not allow any fluid to get inside the hammer. Use mineral soap
and wet cloth to clean the impact hammer surfaces. Do not use petrol
or other cleaning agents that can be detrimental to plastic elements.
• When use of extension cord is necessary, always remember to use
appropriate one (up to 15 m, section 1.5 mm
do napraw gwarancyjnych
2 ; between 15 and 40 m,
section 2.5 mm ). Extension cord should be fully unwound.
2
• Do not use three jaw drill chuck when the hammer drill is set to
impact drilling or chiselling mode. This chuck is designed only for
regular drilling in wood or steel.
NOTE! The device is intended for indor use only.
Even though the design is safe in principle and protection means
and additional safety equipment are used, there is always residual
risk of injuries during operation.
i
CONSTRUCTION AND USE
Hammer drill is a hand-operated power tool with insulation class II. The tool
is driven by single-phase commutator motor. Hammer drill can be used for
drilling holes in working modes: with impact, rotation only, digging channels,
or surface processing of materials such as concrete, stone, brick, etc. Range
of use covers repair and building works, and any work from the range of
individual, amateur activities (tinkering).
Use the power tool according to the manufacturer's instructions
only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the
drawing pages of this manual.
SDS-Max chuck
1.
Fixing sleeve
2.
Additional handle
3.
Locking knob for additional handle
4.
Operation mode switch
5.
Switch lock button
6.
Switch
7.
Wheel for rotational speed control
8.
Voltage indicator
9.
Carbon brushes wear indicator
10.
Additional handle
11.
* Differences may appear between the product and drawing.
MEANING OF SYMBOLS
CAUTION
WARNING
ASSEMBLY/SETTINGS
INFORMATION
EQUIPMENT AND ACCESSORIES
Chisels
1.
Drills
2.
Additional handle
3.
Additional handle
4.
Dust cover
5.
Grease container
6.
Transport case
7.
PREPARATION FOR OPERATION
INSTALLATION OF ADDITIONAL HANDLE
Due to safety issues, always use additional handle (3) when
operating the demolition hammer. It can be fixed in any position
from the range of 360 .
O
Disconnect the power tool from power supply.
• Slide the collar and additional handle (3) over cylindrical part of the
demolition hammer body.
• Install connecting screw with supports.
• Join the clamping wheel of the additional handle (4) and the screw
(fig. A).
• Turn the handle for the position that is most comfortable for the work
performed.
• Tighten the locking knob for additional handle (4).
INSTALLATION OF ADDITIONAL HANDLE
Additional handle (11) can be installed in one of the holes on the
6
- 1 pce
- 1 pce
- 1 pce
- 1 pce
- 1 pce
- 1 pce
- 1 pce
